Engine/General Specifications
Scanning Element
One-Dimensional Solid Scanning Through CCD
Printing Process
Twin Laser Beam Scanning & Electrophotographic Printing
Toner Type
Dry, Dual Component
Color / Black & White
Black & White
Output Speed Copy/Print
40 ppm
First Page Out Time
4 Seconds for MP 4054
Warm-Up Time
14 seconds with Standard Operation Panel
Recovery Time From Sleep Mode
4.9 seconds
System Memory
2 GB RAM + 320 GB HDD (Shared)
Maximum Copy Quantity
Up to 999
Document Feeder Type
Single Pass Document Feeder (SPDF)
Document Feeder Original Size
5.5″ x 8.5″ – 11″ x 17″ (A5 – A3)
Document Feeder Paper Weight
Simplex: 11 – 34 lb. Bond (40 – 128 g/m2)
Duplex: 14 – 34 lb. Bond (52 – 128 g/m2)
Document Feeder Capacity
220 sheets
Preset Reduction and Enlargement Ratios
25%, 50%, 65%, 73%, 78%, 85%, 93%, 100%, 121%, 129%, 155%, 200%, 400%
Zoom Range
25% to 400% in 1% increments
Original Type
Book/Sheet/Object
Maximum Original Size
Up to 11″ x 17″
Supported Paper Sizes
Bypass Tray: 5.5″ x 8.5″ – 12″ x 18″ (A6 – A3)
Tray 1 & 2: 5.5″ x 8.5″ – 11″ x 17″ (A6 – A3)
Supported Paper Weights
Duplex: 14 – 68 lb. Bond (52 – 256 g/m2)
Bypass: 14 – 80 lb. Bond (52 – 300 g/m2)
Tray 1 & 2: 16 – 80 lb. Bond (60 – 300 g/m2)
Supported Paper Types
Plain Paper, etterhead, Color Paper, Pre-Punched Paper, Envelopes, Cardstock, Recycled, Preprinted Paper, Bond Paper
Standard Paper Capacity
1,200 sheets (550 sheets x 2 trays, and 100-Sheet Bypass Tray)
Maximum Paper Capacity
4,700 sheets (w/Tandem LCT + Side LCT)
Standard Output Capacity
500 sheets
Maximum Output Capacity
3,625 sheets (Bridge Unit + 1 Bin + 3,000-Sheet Finisher)
Maximum Monthly Volume
50000
Power Source
120V/60Hz/12A
Typical Electricity Consumption (TEC)
MP 4054: 1.5 kWh/week
Dimensions W x D x H
23.1″ x 26.8″ x 37.9″ (587 x 680 x 963 mm)
Standard Features
Auto Paper Select, Auto Tray Switch, Booklet/Magazine Copy, Center/Border Erase, Chapters, Combine Mode, Cover Insertion, Document Server (3,000 File Capacity), Duplex, lectronic/Rotate Sorting, Full-Color VGA Touch Screen Control Panel, ID Card Copy, 8 Job Presets, 25 Job Programs, Negative/Positive, OHP Slip Sheet, Sample Copy, Series Copy, Simple Screen, 1,000 User Codes, User Stamps
Printer Specifications
Interfaces
Standard: 10Base-T/100/1000BaseTX Ethernet, USB2.0 Type A (2 ports on back of device, 1 port on Operation Panel), SD slot on Operation Panel, USB2.0 Type B
Optional: IEEE 802.11a/b/g/n Wireless LAN, USB Device Server (second NIC), & IEEE 1284 Parallel
Network Protocol
TCP/IP (IPv4, IPv6), IPX/SPX*
Supported Operating Systems
Windows Vista/7/8/XP, Windows Server 2003/2003R2/2008/2008R2/2012/2012R2;
Netware* 6.5 or later, Unix Filters for Sun Solaris, HP-UX, SCO OpenServer, Red Hat Linux, IBM AIX, Mac OS X 10.6 or later, SAP R/3, NDPS Gateway, IBM iSeries/AS/400® using OS/400 Host Print Transform, Citrix Presentation Server 4.5/Citrix Xen App 5.0, 6.0, 6.5
Device Management Utilities
Web Image Monitor, Embedded @Remote, @Remote Office Appliance, @Remote Enterprise Pro, Device Manager NX Lite and Accounting, Device Manager NX Pro and Enterprise, @Remote Connector NX
Printer Languages
Standard: PCL5e/6, Optional: Adobe PostScript 3®, IPDS & XPS
Font Support
PCL5e/6: 45 Scalable Fonts, 13 International Fonts
PS3: 136 Roman Fonts (optional)
IPDS: 108 Roman Fonts (optional)
Print Resolution
Up to 1200 x 1200 dpi
Printer Features
Sample/Locked/Hold/Stored Print
Security Features
HDD Encryption, HDD Data Overwrite, Quota Limit Setting, SMTP over SSL, S/MIME, IPsec Communication, Locked Print Password Encryption, Encrypt Address Book, SSL Secure Socket Layer, Windows/LDAP/User Authentication, SNMP v3, Encryption of Password PDF, Encrypted PDF, IP Filtering
Scanner Specifications
Scan Speed BW Full Color
110 ipm Simplex/180 ipm Duple
Scanning Resolution
Up to 600 dpi
Scan Area
Up to 11″ x 17″
Standard Interfaces
10BaseT/100BaseTX Ethernet
Optional Interfaces
Wireless LAN (802.11a/b/g), Gigabit Ethernet
Protocols
TCP/IP, SMTP, SMB, FTP, POP3, NCP**
File Formats
Single-Page and Multi-Page TIFF, PDF, High Compression PDF, Single-Page JPEG, Single and Multiple page PDF/A
Memory Capacity
Shared with Copier Memory
Scanning Features
Embedded Scan-to-Email, HDD, Folder, URL, Color Scanning
Fax Specifications
Fax Resolution
200 x 200/100 dpi (Standard)
400 x 400 dpi (Optional)
Compression Method
MH, MR, MMR, JBIG
Modem Speed
33.6 Kbps with Auto Fallback
Transmission Speed
G3: 3 seconds per page (MMR Compression)
G3: 2 seconds per page (JBIG Compression)
SAF Memory
4 MB standard/60 MB maximum 320 pages/4,800 pages
Group Dials
100 (max. 500 numbers per group)
Fax Features
Dual Access, Duplex Reception, Image Rotation, 1 Hour Backup, LAN-Fax Capability, Internet Faxing (T.37), IP Faxing (T.38), Fax Forwarding to E-Mail/HDD/Folder
Optional Features
Simultaneous operation of up to 3 lines (G3 x 3)
